System Design 101: Designing a Scalable URL Shortener (Part 1)

In the last post, we unpacked the core concepts of system design — latency vs throughput, load balancing, caching, the CAP theorem, and scaling strategies. Today, we’ll apply those ideas to a real-world scenario: building a URL shortener, just like Bitly or TinyURL.

At first glance, it sounds simple:

• Paste a long URL

• Get a short link

• Click the short link

• Get redirected to the original URL

But as with most systems at scale, simplicity on the surface hides complex decisions underneath. Let’s peel back the layers.

---

Step 1: What Are We Building?

Before we think about servers or databases, we need to clearly define what the system should do.

Functional Requirements

• Accept a long URL and return a short version

• Redirect short URLs to the original long URL

• Optionally track clicks (e.g. count or timestamp)

Non-Functional Requirements

• Low latency: Redirection must be nearly instant

• High availability: Links should work reliably 24/7

• Scalability: Support millions (or billions) of URLs and redirects

• Fault tolerance: The system should continue operating even if parts fail

These are the real drivers of good system design — and where our core concepts come into play.

---

Step 2: The Naive Version

Let’s say we’re building a prototype.

• One web server handles requests

• One database table stores mappings like:

short_code | long_url
abc123     | https://example.com/my-very-long-url

• A form submits the long URL → a short code is generated and saved

• A redirect endpoint matches the code and redirects the user

This works fine… until it doesn’t.

• Too many users? The server crashes.

• Database slow? Redirects lag.

• One machine dies? The whole system goes down.

Time to scale.

---

Step 3: Enter System Design Principles

Now, let’s level up our architecture using the fundamentals from our last post.

Load Balancing

Instead of one app server, we place a load balancer (like NGINX, HAProxy, or AWS ELB) in front of multiple app servers.

• It distributes incoming traffic evenly

• Prevents any single server from becoming overwhelmed

• Increases fault tolerance by rerouting requests

This improves throughput and protects against downtime.

Caching

URL redirection is read-heavy. Why hit the database for every redirect?

Enter caching:

• Store frequently used short_code → long_url mappings in Redis or Memcached

• Keep cache TTL (time-to-live) reasonably high

• Hit the cache first, database second (read-through strategy)

This significantly improves latency and reduces database load.

CAP Theorem

Let’s say a database node becomes unreachable. Should the service:

• Refuse to redirect (prioritize Consistency), or

• Redirect with possibly outdated data (prioritize Availability)?

In most real-world cases, Availability + Partition Tolerance (AP) wins. Slightly stale metrics are okay — but broken links aren’t.

Scaling Up

We scale horizontally:

• Add more app servers behind the load balancer

• Add more cache nodes for high-speed reads

• Consider a distributed database (like DynamoDB or Cassandra) to handle enormous write volumes

Vertical scaling (adding CPU/RAM to one machine) hits a ceiling fast. Distributed systems are how you grow sustainably.

---

What’s Next?

We’ve laid the foundation. In the next part, we’ll dig deeper into:

• Short code generation: How to create unique, collision-free short links (base62, hashing, randomization)

• Database design: How to store, retrieve, and scale your URL mappings

• Analytics tracking: How to record and report on clicks with minimal performance impact

Stay tuned — this is where the real system design decisions begin.

---
